| ITEMS |
UNIT |
YV1000A |
YV1000ATC |
YV1000ATC+C |
| CAPACITY |
| Table diameter |
mm |
ø 1000 |
ø 1000 |
ø 1000 |
| Max. swing |
mm |
ø 1350 |
ø 1350 |
ø 1350 |
| Max. cutting diameter |
mm |
ø 1100 |
ø 1100 |
ø 1100 |
| Max. cutting height |
mm |
900 |
900 |
900 |
| Max. load Table |
kg |
4000 |
4000 |
4000 |
| Travel |
| Horizontal travel of rail head (X-axis) |
mm |
-40,+720 |
-40,+720 |
-40,+720 |
| Vertical travel of ram (Z-axis) |
mm |
800 |
800 |
800 |
| Spindle |
| Table speed |
(Low) |
rpm |
1~160 |
1~160 |
1~160 |
| (High ) |
rpm |
160~600 |
160~600 |
160~600 |
| Led spindle speed |
(Low) |
rpm |
-- |
-- |
2~1200
1200~2400 |
| (High) |
rpm |
| Max. Table torque |
N.m(kgf-m) |
8,247(841) |
8,247(841) |
8,247(841) |
| Feeder rate |
| Rapid traverse of rail head (X-axis) |
M/min |
12 |
12 |
12 |
| Rapid traverse of ram (Z-axis) |
M/min |
10 |
10 |
10 |
| Cutting feed rate |
mm/min |
1~2000 |
1~2000 |
01~2000 |
| Manual feeder rate |
m/min |
0~6 |
0~6 |
0~6 |
| Tooling |
| Turret (ATC) type |
|
-- |
12 tools |
16 tools |
| Type of tool shank |
|
-- |
7/24 taper BT-50 |
7/24 taper BT-50 |
| Max. of tool size for automatic tool
changing |
mm |
-- |
380 |
| Max. tool weight |
kg |
50 |
50 |
50 |
| Max. loading of ATC |
kg |
-- |
360 |
360 |
| Tool change time(ATC) |
Sec |
5 |
40 |
40 |
| Turret |
| Turret (ATC) type |
|
5 station |
-- |
-- |
| Square tool holder (Applicate tool
size) |
mm |
 32x32(ø 63) |
-- |
-- |
| Motors |
| Spindle drive motor |
kw |
37/45 (α40) |
37/45 (α40) |
37/45 (α40) |
| #2 Spindle drive motor |
kw |
-- |
-- |
7.5/11(α8) |
| X-axis servo motor |
kw |
7 (α30i) |
| Z-axis servo motor |
kw |
6 (α40iß) |
| CF-axis servo motor |
kw |
-- |
-- |
7 (α30i) |
| Coolant motor |
kw |
1.5 |
1.5 |
1.5 |
| Tank capacity |
| Hydraulic tank |
L |
60 |
60 |
60 |
| Coolant tank |
L |
750 (square) |
| Lube. Tank(slide ways) |
L |
4.6 |
| Power sources |
AC220±10%. 60Hz±5Hz |
| Power capacity |
KVA |
65 |
65 |
65 |
| Floor dimension |
mm |
4000X4800X4950 |
| Machine weight |
kg |
20,000 |
20,000 |
21,000 |
| Positioning accuracy of linear axis |
mm |
P:±0.007/500,
Ps:±0.005(X&Z), P::±7.5"/360° Ps:±5"(C-axis) |
| • Specification subject to
change to change without prior notice. |
|
|
